Flexible water hoses
HONGWU flexible water hoses are manufactured according with EN ISO10380, available from DN8 to DN50.
Contact us
Previous：EN15266 flexible gas piping system
Features:
Quick& Easy Installation
Required Tools: Tubing Cutter, Wrenches, clamping tool
Fewer Fittings, Less Waste
Pre-Marked by the meter
Light weight & Flexible
100% Factory Pressure Tested
Norm: EN ISO 10380
Bright annealed (in hydrogen atmosphere by 1050 - 1100°C)
Tubing Material: stainless steel 304/316L
Pipe diameter:DN8-DN50
Dimensional Characteristics
| Dimension | Outer diameter | inner diameter | material thickness | |
| DN8 | 12 | 8 | 0.25 | Customization is acceptable |
| DN12 | 16 | 12 | 0.3 | |
| DN15 | 20 | 16 | 0.3 | |
| DN20 | 25 | 20 | 0.3 | |
| DN25 | 33 | 26 | 0.3 |
